INPUT OPERATION STAGE (GENERIC FUNCTIONS)
OPERATION ON INPUT ON/OFF
10 Hz
20 Hz
50 Hz
80 Hz
150 Hz
220 ms
110 ms
45 ms
30 ms
15 ms
ATTENTION: time T must be ≥
to Tmin
Auto-calibration
Reset totalizes
Block totalizes
Speed rate Tmin
Block totalizes
Totalizers active
Necessary conditions for enabling the function
Necessary conditions for enabling the function
Necessary conditions for enabling the function
Tmin
T > 1 sec. = Auto zero
POS. 5.7 ENABLED
POS. 5.9 (batch on input 1) DISABLED
POS. 5.10 batch functions assign to input 2 (optional)
DISABLED
POS. 5.1 ÷ 5.4 ENABLED at least one
N.B.: This function is even assignable to the input 2
POS. 5.6 ENABLED
POS. 12.5 (auto-batch) DISABLED
POS. 12.7 (batch consent) DISABLED
POS. 5.8 ENABLE
POS. 5.9 (batch on input 1) DISABLED
POS. 5.10 batch functions assign to input 2
(optional) DISABLED
POS. 6.1-6.4 end-batch functions assign to output 2
1 e/o 2 DISABLED
Necessary conditions for enabling the function
Range change
N.B.: THE FUNCTIONS ABOVE INDICATED ARE ENABLED ONLY ON INPUT 1
Scale 2
Scale 1
