START STOP BATCH
START: it is possible activate the start of batch in two different way:
1. from remote input: assigning the functions of start/stop batch to the input 1 (POS.
5.9) or input 2 (POS. 5.10) and using the input/s like visualized from page 12.
2. from keyboard: short pressing of the key
N.B.: the start of batch from keyboard is always on the descent front (release of the
key) and is not available with the function of batch consent (POS. 12.7)
STOP: the stop of batch can be due to three events:
1. keyboard or remote input (manual stop): short pressing of the key
2. end of batch: in this case the stop of batch will have activated from a output signal to
the attainment of the batch quantity
3. maximum time of batch: if a maximum batch time has been set and this is exceeded,
the batch in progress is stopped independently from the batched quantity
Notes:
q during the batch the symbol of the active batch and the name of the formula are
visualized on video.
q When the batch outputs are enable, pushing for more of 5 sec. the key , the outputs
will remain energized till the key is released. On the display, in place of the CT and ST
totalisers the following messages will appear:
!! VALVE !!
!! OPENED !!
IMPORTANT NOTES
The start of the batch disables any function listed below:
To optimize the performances of the meter used as a batch instrument, it is recommended to set it
as prompt as possible according to the plant requirements, choosing the opportune values of time
constant (pos. 3.1) and acceleration threshold (pos. 3.2).
POS 12.5 POS 12.6 POS 5.6 POS 12.1 POS 5.9 POS 3.7-5.8 POS 3.8 POS 5.7
* SE UTILIZZATO INGRESSO 1
** VALORE A ZERO
AUTO BATCH BM AUTO SEL
BLOCK TOTALIZER
N. SAMPLES
INPU
T 1 ON START/STOP
BATCH
AUTO RANGE CHANGE OR
FROM INPUT
ENERGY SAVING
CALIBRATION
POS 12.5 AUTO BATCH *DISABLE
POS 12.6 BM AUTO SEL ** DISABLE
POS 12.7 CONS. MODE DISABLE DISABLE * DISABLE
POS 5.9
INPUT 1 ON START/STOP
BATCH
DISABLE DISABLE DISABLE
POS 5.10
INPUT 2 ON START/STOP
BATCH
DISABLE DISABLE DISABLE DISABLE
POS 5.10 BM SELECT DISABLE ** DISABLE
POS 6.1÷6.4 OUTPUT ON END BATCH DISABLE
