22
Replacementparts
Type 2012
11 replacemenT parTs
Caution!
risk of injury and/or damage by the use of incorrect parts!
Incorrect accessories and unsuitable replacement parts may cause
injuries and damage the device and the surrounding area.
▶ Use only original accessories and original replacement parts from
Bürkert.
11.1 replacement part sets
The following spare part sets are available for the globe control valve
Type 2012:
• Seal set, valve set and valve fittings (valve set + seat).
11.1.1 spare parts for seal set
Seal set for actuator PPS:
actuator size nominal diameter Order number
40 10, 15, 20 233 581
50 10, 15, 20, 25 233 582
63 25 - 50 233 583
80 25 - 65 233 584
100 32 - 65 233 585
125 40 - 65 233 586
Seal set for actuator PA:
actuator size nominal diameter Order number
40 10, 15, 20, 25 233 587
50 10, 15, 20, 25 233 588
63 25 - 50 233 591
80 25 - 65 233 593
100 32 - 65 233 594
125 40 - 65 233 596
11.1.2 spare parts for valve set / valve fittings
Valve set (PTFE sealing material), valve fittings (valve set + seat):
dn Order number
Valve set
Order number
Valve fittings
Order number
installation tool 3)
10/15 149 606 149 608 652 604
20 011 171 149 864 652 605
25 011 202 161 376 652 606
25 160 737 149 786 652 606
32 011 208 149 787 652 607
40 011 209 149 788 652 608
50 233 813 237 390 652 609
65 233 815 237 391 655 562
3)
required for valve fittings only
