Rev. 04/02
-8- D901/M
Outputs 4-20 mA, 600 Ohms max., Isolated.
12 Vdc pulse, 50 mS duration, 0-0.15 Hz to
0-2.5 Hz, user adjustable.
Non-linearity
±2 % Full Scale
Sensitivity 0.4 % of Full Scale
Repeatability
±0.4% of Full Scale
Response Time 5-50 seconds, user configured adjustable, to
90% of value, step change in flow.
Enclosure NEMA 4X, [IP-65] Fiberglass w/SS
hardware.
Size 13.5H x 11.3W x 5.60D inches
[343H x 287W x 141D mm]
Mounting Wall mount
Weather Shield Optional weather visor; Dynasonics P.N.
D003-899-001
Net Weight 15 lbs. [ 6.8 Kg ]
PART 1 - SPECIFICATIONS
