Rev.
04/02 -16- D901/M
The enclosure should be mounted in an area that is
convenient for servicing, calibration or for observation of
the LCD readout.
1. Locate the transmitter within the length of transducer
cable that was supplied with the D901/M system. If
this is not possible, do not attempt to add additional
cable to the transducer. Contact the Dynasonics
factory to coordinate an exchange for the proper cable
length. Transducer cables that are up to 300 feet [90
meters] are available.
2. Mount the D901/M transmitter in a location that is:
PART 2 - TRANSMITTER INSTALLATION
Transmitter Installation
Figure 8
