Rev.
04/02 -24- D901/M
The VOL. PULSE key allows the entry of a totalizer
exponent. This feature is useful for accommodating a
large accumulated flow. The exponent is a “ X 10 “
multiplier, which can be from 0 (no multiplier) to 2 (X 100).
For example, to totalize in GAL X 100, a VOL. PULSE
value of 2 would be used (10
²
or 100).
Acceptable input range for the VOL. PULSE constant is
shown in Table 5.
* Note: If an entry greater than 2 is attempted, the meter
will display OVER!. If a non- whole number value is
attempted, the meter will display RANGE!. A legitimate
value will need to be entered.
After a VOL. PULSE value is entered, the display will
reflect the unit as 0=10º=X1, 10¹=X10 and 2=10²=X100.
Table 6 illustrates various codes and their display results.
I.D. US METRIC
Max 2 2
Min * 0 0
Table 5
PART 3 - STARTUP AND CONFIGURATION
Totalizer Exponent
Input
VOL. PULSE
CODE ENG. NOTATION DISPLAY MAXIMUM
0 10E0 999,999
1 10E1 999,999
2 10E2 999,999
Table 6
