Dynasonics 901 Series Enhanced Ultrasonic Flow Meter - Manual (Page 5)

Rev. 04/02
-4- D901/M
TABLE OF CONTENTS
Pages
Instrument Startup and Configuration
CAL. Constant Input 26
Display Damping 27
System Damping 27
TEST Diagnostic Key 27
System and Totalizer RESET 28
Totalizer Reset 28
Trouble Shooting Guide 29-30
Appendices 31+
Face Plate Drawing
Intrinsically Safe Installation
High-Temperature Transducers
Clean Liquid Installation Guide
Multiple Unit Cross-talk
Pipe Dimension Chart: Cast Iron
Pipe Dimension Chart: ST, SS, PVC
Velocity to Volumetric Conversion
Statement of Warranty
Customer Service
Part 4 - Troubleshooting
