43
SYMBOL EXPLANATIONS
FLOW METER INSTALLATION
! Caution—Refer to accompanying documents
IMPORTANT NOTE:
Not following instructions properly may impair
safety of equipment and/or personnel.
IMPORTANT NOTE:
Must be operated by a Class 2 supply suitable for
the location.
IMPORTANT NOTE:
Do not connect or disconnect either power or
outputs unless the area is known to be non-
hazardous.
IMPORTANT NOTE:
Do not connect the interface cable between a
FUSION flow meter and a personal computer
unless the area is known to be non-hazardous.
WARNING:
EXPLOSION HAZARD - SUBSTITUTION OF
COMPONENTS MAY IMPAIR SUITABILITY
FOR CLASS I, DIVISION 2
!
!
!
!
DYNASONICS
8635 Washington Avenue
Racine, WI 53406
Toll-Free in U.S. and Canada:
Tel: (800) 535-3569 Fax: (800) 732-8354
Tel: (262) 639-6770 Fax: (262) 639-2267
www.dynasonics.com
!
