19
6. CONFIGURATION
The FUSION meter has two basic sets of programming
procedures: List Item Selection and Numeric Value Entry. It also
has two configuration menus—Basic and Advanced.
List Item Selection Procedure
Note: If you are already in PROGRAM mode and the selection to
be viewed or changed is already displayed, proceed to step 3
below. If you are in PROGRAM mode and the selection to be
viewed or changed is not displayed, press the
▲ or ► arrow keys
and repeat pressing until the desired selection appears. Proceed
to step 3.
1. To access the Basic menu, press the MENU key for less than
three seconds and release the key. The unit will enter the
Basic menu. To access the Advanced menu, press and hold
the MENU key for more than three seconds and release the
key.
2. Press the ► key to move to the desired selection.
3. Press ENTER to view the current selection.
4. If the current selection is desired, press ENTER to confirm.
The unit will automatically advance to the next selection.
5. If the current selection must change, press the ► key and
repeat pressing to scroll through the available choices. Press
ENTER to confirm your selection. The unit will automatically
advance to the next selection.
6. To exit PROGRAM mode, press the MENU key. Depending on
your position in the PROGRAM mode, up to three MENU key
presses may be required to exit. The display will change to
RUN mode.
IMPORTANT: The FUSION software is structured using two
menus—a Basic menu and an Advanced menu. Pressing the
MENU key for less than three seconds places the user into the
Basic menu. Pressing and holding the MENU key for more than
three seconds will place the user into the Advanced menu. A
Map of the user interface is included in the Appendix of this
manual. The Map provides a visual path to the configuration
parameters that users can access. This tool should be
employed each time configuration parameters are accessed or
revised.
