42
Description Specification
Input Voltage 12-30 VDC @ 100 mA Max; Class 2 Supply
Flow Range
1-Inch 0.7—60 GPM [24-2057 BPD]
3-230 LPM [0.18-13.8 M3/H]
Accuracy 1% of Rate over the top 10:1 measuring
range; 0.1% of full scale at rates less than
this range
Pressure
Temperature 300 PSI [2,070 kPa]
-30 to +160 °F [-34 to +70 °C]
Outputs
4-20mA
Rate Pulse
Total Pulse
RS485
(FUSION cannot output 4-20mA and Rate Pulse
simultaneously. Only one can be selected.)
12-bit; source from DC supply voltage
0-1,000 Hz; open collector; internal/
external pull-up; TTL square-wave or
turbine simulation; 50% duty cycle, sink
100mA max
Open collector, internal/external pull-up;
33 mSec duration, sink 100mA max
1/4-node; 128 drop, Modbus command set
Rate Units
Total Units GPM, BPD, LPM, M3/H
GAL, BBL, LIT, M3
Wetted Materials 316 SS, polyetherimide, Buna-N
Enclosure
Ports
TYPE 4; powder coated aluminum, SS,
polycarbonate, urethane, PVC
(2) 1/2” NPSM and (1) 3/4” NPSM
Display Flow Rate: auto ranging 4-digit LCD
Flow Total: 8-digit, E-2 to E+3
Approvals Class I Division 2 Groups C, D; CSA 22.2
No. 142 & 213; UL 508, ISA 12.12.01; File
215035
Protection Reverse polarity; auto-reset polyfuse;
transient voltage suppression
PRODUCT SPECIFICATIONS
