BAUD RATE—Modbus communications baud rate
9600 - 9600 Baud
19200 - 19.2K Baud
Select the required baud rate from the list.
Standard Modbus Implementation
A subset of the standard Modbus commands is implemented to
provide access into the data and status of the FUSION Meter.
The following Modbus commands are implemented:
Opcode 04 – Read Input Registers
This opcode returns the input registers, such as flow rate or
totalizer. All data is returned as 16 bit values with the MSB first
as required by Modbus
The following Input Registers are defined:
Command Description
04 Read Input Registers
05 Force Single Coil
Modbus Register Starting Address Description
30001 <00><00> Normalized flow rate
30002 <00><01> Spares
30003 <00><02> MS Word of Totalizer
30004 <00><03> LS Word of Totalizer
30005 <00><04> TT Velocity (in .1 ft/sec)
30006 <00><05> Doppler Velocity (in .1 ft/sec)
30007 <00><06> TT Success Rate (0-100)
30008 <00><07> Doppler Signal Strength (0-100)
30009 <00><08> Doppler Gain (0-64)
30010-30016 <00><09> Doppler Filter (0-3)
30011-30016 <00><0A> to
<007><0F>
Spares
