Electrical Connection
The power for all modules is taken from a suitable circuit
breaker/fused disconnect power supply within the main
panel. The electrical service enters the individual modules
through the top into the module’s control panel enclosure.
Proper grounding of the module is mandatory. Before
ƒ””›‹‰‘—–ƒ›‡Ž‡ –”‹ ƒŽ™‘”ǡ ‘Ƥ”–Šƒ––Š‡ƒ‹
supply is isolated. A typical power wiring is located on page
46 – Power Distribution Drawing. Knockout drawings are
provided. Do not drill into cabinet; shavings can damage
electronic components. The power for all individual modules
shall be in compliance with all local and national codes.
CoolLogic‘–”‘Ž›•–‡‹”‹‰
A separate 115 volt power supply is required to power the
CoolLogic Master Control Panel. Communication between
the Master Control Panel and chiller modules requires a
simple two-conductor 18 AWG shielded cable with drain
rated at 60°C minimum, daisy chain connection. Control
™‹”‹‰ ƒ‘–„‡‹•–ƒŽŽ‡†‹–Š‡•ƒ‡ ‘†—‹–ƒ•Ž‹‡
voltage wiring or with wires that switch highly inductive
loads such as contactor and relay coils. Refer to the Power
Distribution schematic on page 46 of this manual for more
information. All wiring shall be in compliance with all local
and national codes.
Electrical Phase Sequencing
Proper clockwise rotation for scroll compressor motors
is important to prevent damage to the compressors.
ClimaCool recommends the use of a phase sequence
indicating instrument following the manufactures
directions. An alternative is to “bump test” the compressors
one at a time with pressure gauges attached to the high and
low gauge ports of the compressors to check for proper
rotation. Energize the compressor for a few seconds to
‡•—”‡–Š‡†‹• Šƒ”‰‡’”‡••—”‡‰ƒ—‰‡‹ ”‡ƒ•‡••‹‰‹Ƥ ƒ–Ž›Ǥ
If the discharge pressure does not increase, proper
rotation is reversed. Compressor rotation can be reversed
by opening the main electrical disconnect and switching
any two of the main power supply leads feeding that
compressor’s contactor.
Proper Voltage Balance
Occasionally, in three phase circuits, a voltage imbalance
occurs between phases. It is not recommended to operate
equipment when an imbalance greater that 2% occurs. This
ƒ—•‡•‘–‘”•–‘”—ƒ–Š‹‰Š–‡’‡”ƒ–—”‡•ƒ†ƒ›ƒơ‡ –
their longevity. The following example describes how to
calculate the average voltage of the three phases to see if
the imbalance is greater than 2%.
Example: Line 1 = 226v Line 2 = 230v Line 3 = 228v
The average is: (226+230+228) / 3 = 228v
Next, [100(228-226)] / 228 = 0.9%
The voltage imbalance of the three phase circuit is 0.9%.
This is well under the 2% range.
Voltage/Phase Monitor
‘Ž–ƒ‰‡Ȁ’Šƒ•‡‘‹–‘”•ƒ”‡ˆƒ –‘”›•—’’Ž‹‡†ˆ‘”Ƥ‡Ž†
installation with the CoolLogic Master Control Panel. The
voltage/phase monitor helps guard the chiller bank against
˜‘Ž–ƒ‰‡ƪ— –—ƒ–‹‘•ǡ’Šƒ•‡ˆƒ‹Ž—”‡‘”’Šƒ•‡”‡˜‡”•ƒŽ
conditions which could void your warranty. The voltage/
phase monitor has three wires that connect to the main
three phase power chiller bank input. Two low voltage
control wires are connected to the CoolLogic Master Control
Panel. Do not install control wiring in the same conduit
as line voltage wiring or with wires that switch highly
inductive loads such as contactor and relay coils. Note: It
‹•ƒ†ƒ–‘”›–‘‹•–ƒŽŽ‘‡ȋ͕Ȍ‘‹–‘”’‡”„ƒƒ–ƒ‹
’‘™‡”†‹•–”‹„—–‹‘’ƒ‡Ž–‘‘‹–‘”˜‘Ž–ƒ‰‡ƒ†’Šƒ•‹‰
‘ˆ’‘™‡”–‘–Š‡‘†—Ž‡•Ǥ‡‡‹”‹‰‹ƒ‰”ƒ‘’ƒ‰‡͖͖Ǥ
