6.8 UNBALANCE SPLIT
Use of the wheel balancing machine
With the wheel in the outside correction position, 1.
press the button to release it.
Sele 2. ct a spoke close to the position indicated by the
laser and press the button
T
he WhITe lINe oN The RIm INdIcATes The uNbAlANce
coRRecTIoN posITIoN NoT splIT .
I
f The symbol AppeARs
,
IT meANs ThAT you cANNoT
selecT The fIRsT spoKe AT ThAT poINT
(
mAxImum dIsTANce
150°).
Turn the wheel in the direction indicated on the screen 3.
and select the second spoke by pressing the button
I f The symbol AppeARs , IT meANs ThAT you cANNoT
selecT The secoNd spoKe AT ThAT poINT
(
mINImum dIsTANce
18°,
mAxImum dIsTANce
120°).
At this stage, two indications appear on the screen for 4.
positioning of the unbalance correction weights.
To cancel the split, press the button :
Any error in this procedure is clearly shown on screen.
The split function is enabled for the outside of aluminium rims ( aLUMiniUM riMs ) and is used to hide any adhesive
unbalance correction weights behind the rim spokes.
To split the unbalance measured in two different positions, proceed as follows:
