CEMB USA ER100 - Manual (Page 2)

6.3 UNBALANCE UNIT OF MEASURE SELECTION 20
6.4 UNBALANCE MEASUREMENT (FIRST SET OF BUTTONS) 21
6.4.1 Lock/release wheel in correction position 22
6.5 UNBALANCE MEASUREMENT (SECOND SET OF BUTTONS) 23
6.6 THRESHOLD DISPLAY 24
6.7 UNBALANCE CORRECTION 25
6.7.1 Iron rims 25
6.7.2 Aluminium rims 26
6.7.3 Change weight application distance 27
6.8 UNBALANCE SPLIT 28
6.9 UNBALANCE OPTIMISATION 29
6.10 TYRE SET 30
6.10.1 Tyre set value certificate 32
6.10.2 Tyre set certificate customisation 32
6.11 WEIGHT STATISTICS 33
6.12 BALANCING CERTIFICATE PRINTOUT 35
6.12.1 Balancing certificate customisation 36
6.13 SCREENSAVER 40
6.14 WHEEL ANALYSIS 41
6.14.1 Runout 42
6.14.1.1 When and why To use mATChIng 42
6.14.1.2 matching 43
6.14.1.2.1 When to perform matching 44
6.14.1.2.2 how to perform matching 45
6.14.1.3 Peak/peak and first harmonic graphs 45
6.14.2 Tread 46
6.14.3 Taper 48
6.15 OUTSIDE RIM RUNOUT 49
7. wHEEL dISMoUNtING 51
8. SEtUp 52
