450302-5 Telephone: (508) 678-9000 / www.amdry.com 3
Control Door Assembly Without Trim
For Non-Coin Models Mfd. as of July 13, 1998
Illus. No. Part No. Qty. Description
1 881053 1 ADC Logo Only (with double adhesive tape)
870011 1 Logo Double Tape Kit
2 882265* 1 Control Door
(includes illus. nos. 2 and 3)
3 117604 4 Neoprene Sponge Tape (sold by the foot)
4 150300 4 #10 x 1/2” Hex Washer TEK Screw
5 102603 1 Control Door Rod Support Catch
6 102601 1 Control Door Retainer Clip
7 102502 1 Control Door Support Rod
8 882541 2 Spring Turn Latch Assembly
* Specify color when ordering.
