31
Illus. No.
Part No.
Qty.
Description
1
100109
1
4L-650 V-Belt (to idler assembly)
2
100701
1
3/16” x 3/16” x 1” Key
3
101130
1
5/8” x 2-1/2” Motor Pulley (60 Hz)
101139
1
5/8” x 2-3/4” Motor Pulley (50 Hz)
4
120200
1
3/8” x 90° Connector
5
181003
1
1/2 hp 208/230/380/460v 3ø 50/60 Hz Totally Enclosed, Fan-Cooled Motor
(56Z frame)
6
150501
4
5/16-18 x 3/4” Hex Head Machine Bolt
7
153002
4
5/16” Lock Washer
8
153001
4
5/16” Flat Washer
9
100075
1
1 hp 208/230/380/460v 3ø 50/60 Hz Totally Enclosed, Fan-Cooled Motor
(56Z frame)
10
120200
1
3/8” x 90° Connector
11
150501
4
5/16-18 x 3/4” Hex Head Machine Bolt
12
153002
4
5/16” Lock Washer
13
153001
4
5/16” Flat Washer
14
154000
8
5/16” Tinnerman
15
152004
4
5/16”-18 Hex Nut
16
153002
4
5/16” Lock Washer
17
153001
4
5/16” Flat Washer
18
800920
1
Reversing Motor Mount Only (56Z frame)
(includes illus. no. 19)
881067*
1
Reversing Totally Enclosed, Fan-Cooled Motor Mount Assembly Complete
(includes illus. nos. 2 through 14 and 18 through 24)
For 60 Hz Models Only
881066*
1
Reversing Totally Enclosed, Fan-Cooled Motor Mount Assembly Complete
(includes illus. nos. 2 through 14 and 18 through 24)
For 50 Hz Models Only
19
117600
5
Noise Suppressor Tape (sold by the foot)
20
153050
2
1/2” S.A.E. Flat Washer
21
100702
1
1/8” x 1/8” x 1-1/2” Key
22
100603
1
16” Impellor with 3/4” Bore
23
153050
2
1/2” S.A.E. Flat Washer
24
152006
2
1/2-20 Left Hand Jam Nut
*
Specify voltage when ordering.
Reversing Totally Enclosed, Fan-Cooled Motor Mount Assembly
