450302-5 Telephone: (508) 678-9000 / www.amdry.com 33
Illus. No. Part No. Qty. Description
1 880251 1 1/4” Temperature Sensor Probe Assembly
(includes illus. nos. 1 and 5 through 8)
2 130103 1 225° Large Automatic Thermostat
130301 1 225° Manual Reset Thermostat
3 153010 2 #6 Star Washer
4 152000 2 #6-32 Hex Nut
5 121028 2 Insulated Terminal Only
6 122701 4 Socket Terminal Only
7 122605 1 4-Pin Socket Connector Only
8 154007 2 1/4” Tinnerman Push On Fastener
9 150005 2 #6-32 x 1/4” Round Head Machine Screw
10 801425 1 Microprocessor Sensor Bracket Assembly Complete
(includes illus. nos. 1 through 10)
305007 1 Universal Sensor Bracket Only
11 122604 1 4-Pin Connector Only
12 122700 4 Pin Terminal Only
13 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
14 150005 5 #6-32 x 1/4” Round Head Machine Screw
15 130111 1 130° Large Thermostat
16 130100 1 150° Large Thermostat
17 130103 1 225° Large Automatic Reset Thermostat
130301 1 225° Manual Reset Thermostat
18 130101 1 180° Large Thermostat
19 153010 5 #6 Star Washer
20 152000 5 #6-32 Hex Nut
21 840065 1 Sensor Jumper (4)
22 121028 8 Insulated Terminal Only
23 122701 4 Socket Terminal Only
24 122605 1 4-Pin Socket Connector Only
831702 1 Sensor (4) Bracket Harness Assembly
(includes illus. nos. 22 through 24)
25 801418 1 Non-Computer Sensor (4) Bracket Assembly Complete
(includes thermostats)
(includes illus. nos. 14 through 25)
305007 1 Universal Sensor Bracket Only
26 122604 1 4-Pin Connector Only
27 122700 4 Pin Terminal Only
122801 1 Pin/Socket Extraction Tool
28 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
Sensor Bracket Assemblies
