Coin vault assembly – American Dryer Corp. ADG-50DS User Manual
Page 16
14
American Dryer Corporation
450302-5
Illus. No.
Part No.
Qty.
Description
1
802112
1
Microprocessor Coin Vault Assembly Complete
(includes illus. nos. 1 through 6)
802117
1
Microprocessor Coin Vault Only
802110
1
Non-Microprocessor Coin Vault Assembly Complete
(includes illus. nos. 1 through 6)
802115
1
Non-Microprocessor Coin Vault Only
2
160006
1
Cam For 1/4 Turn Lock Only
3
875061
1
1/4 Turn Lock with Key and Cam
160105*
1
1/4 Turn Mer-Pel Key Only
4
802020
1
1/4 Turn Coin Box Assembly
(includes illus. nos. 2 through 5)
802019
1
1/4 Turn Coin Box Only without Face Plate
125915
1
High Security (Greenwald) Coin Box Only with Key
5
802018
1
1/4 Turn Coin Box Face Plate Assembly
(includes illus. nos. 2 through 5)
6
152014
4
1/4-20 Free Spin Wash Nut
7
102502
1
Control Door Support Rod
8
102601
1
Control Door Rod Retainer Clip
9
102603
1
Control Door Rod Catch
*
Specify key number when ordering.
Coin Vault Assembly
