American Dryer Corp. ADG-50DS User Manual
Page 31
450302-5
Telephone: (508) 678-9000 /
www.amdry.com
29
Illus. No.
Part No.
Qty.
Description
11
153002
4
5/16” Lock Washer
12
153001
4
5/16” Flat Washer
13
117600
4
Noise Suppressor Tape (sold by the foot)
14
154000
4
5/16-18 Tinnerman Nut
15
800919
1
1 hp Motor Mount Only (56Z frame)
(includes illus. no. 13)
803903
1
1 hp 115-230v 1ø 60 Hz Totally Enclosed, Fan-Cooled
Motor Mount Assembly Complete with Plug Motor
(includes illus. nos. 2 through 7 and 13 through 20)
881080
1
3/4 hp 240v 1ø 60 Hz Totally Enclosed, Fan-Cooled
Motor Mount Assembly Complete
(includes illus. nos. 2 through 7 and 13 through 20)
For Models Mfd. as of February 21, 1995
803904
1
3/4 hp 240v 1ø 50 Hz Totally Enclosed, Fan-Cooled
Motor Mount Assembly Complete
(includes illus. nos. 2 through 6 and 13 through 22)
For Models Mfd. prior to February 21, 1995
803905*
1
1 hp 208/230/380/460v 3ø 50 Hz Totally Enclosed, Fan-Cooled Motor
Mount Assembly Complete
(includes illus. nos. 2 through 6 and 13 through 22)
881065*
1
1 hp 208/230/380/460v 3ø 50 Hz Totally Enclosed, Fan-Cooled Motor
Mount Assembly Complete
(includes illus. nos. 2 through 6 and 13 through 22)
16
153050
2
1/2” S.A.E. Flat Washer
17
100603
1
16” Impellor with 3/4” Bore
18
100702
1
1/8” x 1/8” x 1-1/2” Key
19
153050
2
1/2” S.A.E. Flat Washer
20
152006
2
1/2-20 Left Hand Jam Nut
21
120200
1
3/8 x 90° Connector
22
100075
1
1 hp 208/230/380 460v 3ø 50/60 Hz Totally Enclosed, Fan-Cooled Motor
(56Z frame)
100076
1
3/4 hp 240v 1ø 50 Hz Totally Enclosed, Fan-Cooled Motor (56Z frame)
For Models Mfd. prior to February 21, 1995
*
Specify voltage when ordering.
Non-Reversing Totally Enclosed, Fan-Cooled Motor Mount Assembly
