Page 5 II0063A
Service Parts List * N1380-1 Date: 09/03/04
Key No. Part No. Qty. Description
1A N9001 1 Pulley Bushing (.785"ID x 2.79"OD x .695"T)
2 N7212 1 Fan
3 N7403 1 Front Housing & Control Unit
3A N9009 1 Retaining Ring (Beveled)
3B N9010 1 Front Bearing
3C N9008 1 Retaining Ring
3D N7368 1 Cover Plate, Plug Nut Assembly
3E N9450 1 Bracket
4 N7449 1 Rotor, Shaft & Core Assembly
4A N7003 2 Rotor Assembly
4B N7278 1 Core & Shaft Assembly
5 N7280 1 Shell, Stator, Field Coil Assembly
6 N7281 1 End Housing
6A N9302 2 Bearing Seals
6B N9303 1 Rear Bearing (Roller)
6C N9405 1 Tension Bushing
7 N7227 1 Heatsink Assembly
8 N3109 1 Regulator
10 N8051 1 Small Parts Package
1001 N9265 17 Lockwasher (#8 .17"ID x .30"OD x 040" T SST)
1002 N9186 13 TXT-20 Screw (8-32UNC-2A x .37"L)
1003 N9039 6 Pan Head Screw (10-32UNF-2A x .37"L)
1004 N9018 6 Lockwasher (#10 .20"ID x .33"OD x .05"T SST)
1005 N9016 6 Flat Washer (.20"ID x .375"OD x .040"T SST)
1006 N9014 1 Bolt (5/16-16UNC-2A x .75"L)
1007 N9015 1 Lockwasher (.32"ID x .60"OD x.08 "T SST)
1008 N9399 2 Pan Head Screw (8-32UNC-2A x .62"L)
1009 N9400 2 Pan Head Screw (8-32UNC-2A x 1.0"L)
1010 N9447 1 Spacer (.18"ID x .50"OD x .25"T STL)
1011 N9218 1 Hex Nut (3/8-16 Zn)
1012 N9099 18 Flange Locknut (8-32 S-Grip)
1013 N9091 12 Locknut ((10-32UNF-2B)
1014 N9320 12 Flat Washer (.200"ID x .437"0D x 031"T)
1015 N9040 1 Woodruff Key (3/16" x 3/4")
1016 N9217 1 Eyebolt / Nut (3/8-16UNC-2A x 1.75"L)
1017 N9063 1 Flat Washer (.53"ID x 1.06"OD x .09"T BLKOXD.)
1018 N9092 1 Locknut (1/2-20UNF-2B ZN)
*1019 N9587 12 Torx Screw Taptite (10-32 x .5"L)
* - Part not shown on Exploded View.
C. E. Niehoff & Co. • 2021 Lee Street • Evanston, IL 60202 Tech Services Hotline 800-643-4633
