ULTRA EDGE SEQUENTIAL 6

/05/2002

3


RECEIVING INSPECTION

BEFORE REMOVING UNIT FROM ITS PACKAGING, CHECK FOR VISUAL DAMAGE,
ESPECIALLY IF CRATE, SKID, OR CARTON HAS BEEN DAMAGED IN TRANSIT. ANY
DAMAGE CAUSED IN SHIPMENT SHOULD BE IMMEDIATELY REPORTED TO THE
CARRIER. IF UNIT APPEARS IN SATISFACTORY CONDITION, REMOVE ALL PACKING
AND WIPE RUST PREVENTIVE FROM ROLLERS WITH MILD SOLVENT.

1 INTRODUCTION

IMPORTANT
Before turning the system on for the first time, verify that installation has been completed according to
the Installation manual and the main input voltage is 220 VAC, single phase.

The P/A Industries Ultra Edge Sequential Servo Roll Feed (Ultra Edge Sequential) is a state of the art AC Servo feed,
which simplifies Operator adjustments to feed parameters. These Operator adjustments are entered into the control
memory through the keypad. With the use of positional limit switches, the process equipment signals the feeder when
to begin moving the strip, when the feed pitch must be completed, when the process equipment has completed its down
stroke, and with optional pneumatic pilot release, when to open the rolls for piloting.

The Ultra Edge Sequential performs a job when the application requires:

a) use of selectable tool/gag combination along with selectable feed length for every press cycle. (Press

application);

b) use of selectable punch/press combination along with selectable feed length for every feed cycle – (Punching

Bench or Multiple Press application);

The mechanical simplicity, accuracy, and ease of use of the Ultra Edge Sequential will help to improve your quality
and production for years to come.

2

THEORY OF OPERATION

2.1 MECHANICAL

ASSEMBLY

Mechanical assembly consists of:

1) Adjustment/Mounting bracket
2) Feeder
3) Servomotor
4) Mechanical pilot release actuator (optional)

2.2 ELECTRICAL

CONTROL ENCLOSURE ASSEMBLY

Electrical control enclosure consists of:

1) Control switches/buttons/relays
2) Power supply, 24 VDC/5 VDC
3) Servo drive
4) Data entry terminal
5) Cabling
6) Jog Pendant
