ULTRA EDGE SEQUENTIAL 6

/05/2002

22

D e l e t e T o o l # 1
P r e s s 1 t o c o n f i r m
A n o t h e r k e y t o a b o r t

Press “1” key.


T o o l # 1 D e l e t e d

4.9 HOW TO ACTIVATE A TOOL

NOTE: Make sure that the PROGRAMMING “LOCKED / UNLOCKED” key switch is in “Unlocked
position and FEED STATUS screen is displayed. If the current screen is not FEED STATUS one then press
the “OPER” key to bring it up.


Press “TOOLS” key, position the pointer next to Activate tool command and press the “ENTER” key.

E d i t T o o l
A c t i v a t e T o o l <
C r e a t e N e w
P r e s s T O O L S t o e x i t



A c t i v a t e T o o l #

A r r o w k e y s t o s c r o l l
P r e s s T O O L S t o e x i t

Enter the desired tool number or select it from the tool list using

and keys and press the “ENTER” key again.

A c t i v a t e # 1 2 3 4 5 6 7

A r r o w k e y s t o s c r o l l
P r e s s T O O L S t o e x i t


T o o l A c t i v a t e d

4.10 HOW TO EDIT “SETUP” PARAMETERS

NOTE: Make sure that the PROGRAMMING “LOCKED / UNLOCKED” key switch is in “Unlocked
position and FEED STATUS screen is displayed. If the current screen is not FEED STATUS one then press
the “OPER” key to bring it up.
