Buffer 0 is the factory default setup.
F3: STORE - Stores the current front-panel setup to the specified storage buffer. Change the buffer number by using
the numeric keypad or the rotary input knob. Valid storage buffer numbers range from 1 to 49. Below is a
list of parameters that can be stored in each buffer.
Note: Location 50 is for last working setup before power down.
List of Stored Parameters
Stored Parameters
FREQUENCY
RATE(ARB)
AMPLITUDE
FUNCTION
OFFSET
REPETITION
MODE
N-BURST
START ADRS
WAVELENGTH
TRIG SOURCE
OUTPUT
SWEEP
MODULATION
**The RECALL and STORE function can be used as a tool to store and locate many arbitrary waveforms.
Because the 4076 and 4079 are designed with one large memory bank (up to 4,000,000 points of storage),
users can have the freedom to store as many waveforms of different lengths as they desired in a dynamic
fashion (with the limit of total points not to exceed memory capacity). Then, by using STORE and
RECALL functions to save the starting address and lengths of each created arbitrary waveforms, users can
quickly locate (in the memory) and output each of the different waves. These functions can behave like
reference points, so users can actually save up to 49 different waveform reference points in the memory.
See example illustration below to see how it works:
1 4,000,000
Waveform 1 Waveform 4 Waveform 2 Waveform 3
A pts. B pts. C pts.
D pts.
A pts. + B pts. + C pts. + D pts. ≤ 4,000,000 pts.
Point Point
