Page 104
98
Performance Tests Results
Setting
Minimum reading
Maximum reading
Reading
Frequency DDS
1 MHz
999990 Hz
1000010 Hz
Frequency ARB
1 MHz
999950 Hz
1000050 Hz
Sine Amplitude
10Vp-p
3.493V
3.578V
5Vp-p
1.743V
1.792V
3Vp-p
1.043V
1.078V
1Vp-p
0.343V
0.364V
100mVp-p
31mV
40mV
50mVp-p
14mV
22mV
Square Amplitude
10Vp-p
4.940V
5.060V
5Vp-p
2.465V
2.535V
3Vp-p
1.475V
1.525V
1Vp-p
0.485V
0.515V
100mVp-p
44mV
56mV
50mVp-p
20mV
31mV
ARB Amplitude
10Vp-p
3.493V
3.578V
5Vp-p
1.743V
1.792V
3Vp-p
1.043V
1.078V
1Vp-p
0.343V
0.364V
100mVp-p
31mV
40mV
50mVp-p
14mV
22mV
Offset Accuracy
+4V
3.950V
4.050V
+2V
1.970V
2.030V
0V
-10mV
+10mV
-2V
-1.970V
-2.030V
-4V
-3.950V
-4.050V
Sine Distortion
1 KHz
- 65 dB
Square Transition
1 MHz
6 ns
Variable Duty Cycle
20%
19.50%
20.50%
50%
49.50%
50.50%
80%
79.50%
80.50%
