10
PWM,FRQ
PWM frequency. Only
carry wave is PULSE
wave.
PWM,DEVI
Duty cycle deviation.
Only carry wave is Pulse
Wave.
PWM,MDSP
PWM modulation wave.
Only carry wave is
PULSE wave.
PWM,SRC PWM signal source.
PM,DEVI
PM phase offset. Only
PM signal source is set
to INT.
ASK,SRC ASK signal source.
ASK,KFRQ
ASK key frequency. Only
ASK signal source is set
to INT.
FSK,KFRQ
FSK frequency. Only FSK
signal source is set to
INT.
FSK,HFRQ FSK jump frequency
FSK,SRC FSK signal source
CARR,WVTP
Value of carrier wave
type.
CARR,FRQ Value of frequency.
CARR,AMP Value of amplifier.
CARR,OFST Value of offset.
CARR,SYM Value of symmetry.
CARR,DUTY
Value of duty cycle.
Only Square can set this
parameter.
CARR,PHSE Value of phase.
CARR DLY Value of delay.
Note: If Carrier wave is Pulse or Noise you cannot set the modulation waveform.
where:
:={ON,OFF}
:= {INT,EXT}
:={SINE,SQUARE,TRIANGLE,
UPRAMP,DNRAMP,NOISE,ARB}
:= {0.002Hz to 20000Hz}
