57
Figure 6.17
11) Select the Control Unit entry to enter the System Menu option
screen, and choose the desired Control Module entry for DTC
information stored in the vehicle’s on-board computer. (Figure
6.18)
Figure 6.18

If there is not any Diagnostic Trouble Code, the display indicates
“No (pending) codes are stored in the module!” Wait a few
seconds or press any key to return to previous screen.
NOTE: In this manner, the scan tool will communicate with
the vehicle being tested. If there is a linking error, please refer
to 3.8 Product Troubleshooting.
NOTE: If the vehicle does not support ABS/SRS
communication, an advisory message shows on the Scan
Tool’s display. Follow the screen instruction to exit the
system.
Select An Option
1.Control Unit
2.Vehicle Information
System Menu
1.ABS/TCS—Anti-Lock Brake/
Traction Control Module
2.RCM—Restraint Control Module
