NCAT -- NOx Aftertreatment Monitor



BP -- Boost Pressure System Monitor



EGS -- Exhaust Gas Sensor Monitor



PM -- PM Filter Monitor

Figure 5.22

5) If the vehicle supports readiness test of “This Drive Cycle”, a

screen of the following displays: (Figure 5.23)

Figure 5.23

6) Use the UP/DOWN scroll button for more PIDs if additional

information is available on more than one page. Or use the
LEFT/RIGHT scroll button to view PIDs in the previous/next
page.

7) Press the ESC button to return to Diagnostic Menu.

Since DTCs cleared

MIL Status

OFF

Misfire Monitoring

N/A

Fuel system monitoring

Comprehensive

component monitoring

Catalyst monitoring

N/A

Heated catalyst monitor

N/A

This Drive Cycle
