20
4. Playback Data
The Playback Data function allows viewing data from last test
recorded by the scan tool.
4.1 Reviewing Data
1) Use the LEFT/RIGHT scroll button to select Playback from
Main Screen (Figure 3.1), and press the OK button. Wait for
the Review Data screen to appear.
Figure 4.1
2) To review data saved in the scan function, select Scan in the
Replay menu. To review data saved in the AbsSrs function,
select AbsSrs in the Replay menu. Then press OK button to
continue.
3) Use the UP/DOWN scroll button to select the desired DTC
entries from Scan menu or AbsSrs menu (Figure 4.2), and press
the OK button.
Figure 4.2
Review Data
1.AbsSrs
2.Scan
AbsSrs
1. Trouble Code
/scan/ABSSRS/USA/GM/saved
Delete Delete All
