Figure 5.11, Figure 5.12 – Autel Autolink AL619 User Manual
Page 30
29
Figure 5.11
2) View live PIDs on the screen. Use the UP/DOWN scroll button
for more PIDs if additional information is available on more than
one page.( Figure 5.12)
Figure 5.12
If the “Graphics” on the bottom appears when a PID is
highlighted, graphic information is available. Select
Graphics to view graph. (Figure 5.13). PID name, current
value, maximum and minimum values are displayed on the
screen.
…………………
Live Data
.
1. Complete List
2. Custom List
Complete List
Numbers of DTCs
0
Fuel system 1 status
OL
Fuel system 2 status
--
Calculated load value
0.0
%
Engine coolant
temperature
-40
0
C
Pause Graphics Save
