47
Figure 5.41
5) Press Yes or OK button to proceed. The scan tool will display
DTC definition as below.
Figure 5.42

Use the LEFT/RIGHT scroll button to view the previous /
next DTC.

Select Save to record code definition.

For manufacturer specific codes, you need to select a vehicle
make on an additional screen to look for DTC definitions.

If definition could not be found (SAE or Manufacturer
Specific), the scan tool displays “Please refer to vehicle
service manual!”
6) Press No or ESC button to return to previous menu.
Trouble Codes
P0005
Fuel Shutoff Valve A Control
Circuit/Open
Save
Input Dialog Box
P0005
Do you want to save and
continue?
Yes No
