46
Figure 5.39
3) Select Save to save the modules data and return to previous
menu. Or press ESC button to exit.
5.11 DTC Lookup
The DTC Lookup function allows user to search definitions of
DTC stored in built-in DTC library.
1) Use the UP/DOWN scroll button to select DTC Lookup from
Diagnostic Menu and press OK button. (Figure 5.3)
2) Wait for the scan tool to display the DTC Lookup screen.
Figure 5.40
3) Select Show and a soft keyboard will pop up. Use
LEFT/RIGHT button and UP/DOWN button to move to the
desired character, then press OK button to confirm.
4) After you input the DTC code, select Finish and the scan tool
will display this code’s definition on screen.
Modules Present
Protocol ID
SAE J1850 PWM $10
Save
DTC Lookup
Only PCBU can be the first letter
to be put in. Only 0~9,a~f for the
rest letters...
Finish Show Esc
