51
Figure 6.5
5) Follow screen entries to select the correct engine model.
(Figure 6.6)
Figure 6.6
NOTE: You may not need to make all the selections, or have
to select other features. For some vehicles, the tool will not
ask for any information before turning to the Function menu.
6) Use the UP/DOWN scroll button to select the desired control
module from the retrieved engine data menu ( in GM’s case,
the selected engine model: 3.6 L(LFX)), and press the OK
button.(Figure 6.7)
Vehicle Type
1.Chevrolet
2.Buick
3.Cadillac
4.Holden
Camara
1.3.6 L(LFX)
2.6.2 L(L99)
3.6.2 L(LS3)
4.6.2 L(LSA)
