54
Figure 6.11
5) Follow the onscreen instruction to save the information and
continue on the procedure, or select the No option or press
ESC button to exit without saving.
6) Choose a specific car series from the Vehicle Specification
menu.(Figure 6.12)
Figure 6.12
7) A screen message will prompt up to inquire the accuracy of the
Vehicle Specification, if the information is correct select the
Yes option to continue, otherwise select the No option on the
screen to exit without saving.
8) Enter correct Vehicle Identification Number (VIN) in the
INPUT DATA menu. (Figure 6.13)
Tear Tag
INPUT DATA
Finish Show Esc
AEB2
Vehicle Specification
1. CF/LCF
2. E-Series Shuttle Bus
3. F-650/F-750
4. Fiesta
5. Focus
6. Focus C-MAX
7. Fusion
8. GALAXY\S-MAX
