Multi-turn actuators SA 07.1 – SA 30.1/ SAR 07.1 – SAR 30.1
Operation instructions with actuator controls AUMA MATIC AM 01.1 / AM 02.1
63
Index
A
Ambient temperature 8
B
Blinker transmitter 35
C
Collective fault signal 34,35
Command signal 37,39,40
Corrosion protection 10,56
Cross sections 18
Current consumption 6,15
D
Direction of rotation 26
Disconnect switches 15
Disposal and recycling 56
DUO limit switching 24
E
Electrical connection 15
Electronic position transmitter RWG
30
2-wire system 31
3-/ 4-wire system 32
EMERGENCY signal 36
Enclosure protection IP 68 55
F
Finish machining of the stem nut 13
Fuses
52
H
Handwheel 19
Heater 15
I
Indicator disc 22,33
Interface board 34
Internet 5
Inverse operation 45,46
L
Limit switching 23,24,27
Local controls 27
Logic board 35
Loss of signal 40
Lubrication 56
M
Mains frequency 6
Maintenance 4
Manual operation 19
Mechanical position indicator 33
Motor protection 54
Mounting positions of the local
controls
14
Mounting to valve/ gearbox 12
N
Name plate 61
O
Output drive types 12
Overvoltage category 6
P
Packaging 10
Pause time 37,51
Position indicator 33
Position transmitter RWG 15,30
Positioner 37
Potentiometer 29
Power supply 6
Protection tube 13
Protective earth 18
PTC thermistors 54
PTC tripping device 27
Push-to-run operation 21,35
R
Rate power 6
Remote indication 29,30
RESET (Selector switch position)
27
Running time 37,51
S
Safety instructions 4
Selector switch 27
Self-retaining 21,35
Sensitivity 43
Service 57
Short description 5
Short-circuit protection 15
Signals 9
Spare parts list 59
Multi-turn actuator 59
Controls 61
Split Range Version 47
Stepping mode
Operating time 49
Pause time 51
Storage 10
T
Technical data 6
TEST (Selector switch position) 27
Test run
26
Thermoswitches 54
Timer 49
Torque setting 25
Transport 10
Tripping torque 25
Type of duty 6
Type of seating 35
W
Wall bracket 16
