Note :
Please state type and commission no. of the device (see name plate) when ordering spare parts. Only original AUMA
spare parts should be used. Failure to use original spare parts voids the warranty and exempts AUMA from any liability.
Delivered spare parts may slightly vary from the representation.
60
Multi-turn actuators SA 07.1 – SA 30.1/ SAR 07.1 – SAR 30.1
with actuator controls AUMA MATIC AM 01.1 / AM 02.1
Operation instructions
001.0 Housing Sub-assembly
002.0 Bearing flange Sub-assembly
003.0 Hollow shaft without worm wheel Sub-assembly
005.0 Worm shaft Sub-assembly
005.1 Motor coupling
005.2 Coupling pin
005.3 Manual drive coupling
005.4 Pull rod
006.0 Worm wheeel
009.0 Planetary gear for manual drive Sub-assembly
010.0 Retaining flange Sub-assembly
017.0 Troque lever Sub-assembly
018.0 Gear segment
019.0 Crown wheel Sub-assembly
020.0 Swing lever Sub-assembly
022.0 Drive pinion II for torque switching Sub-assembly
023.0 Output drive wheel for limit switching Sub-assembly
024.0 Intermediate wheel for limit switching Sub-assembly
025.0 Locking plate Sub-assembly
058.0 Wire for protective earth (pin) Sub-assembly
061.0 Torque switching head Sub-assembly
070.0 Motor (VD motor incl. no. 079.0) Sub-assembly
079.0
Planetary gear for motor drive
(SA/SAR) 07.1 – 14.1 for VD motor)
Sub-assembly
080.0
Planetary gear for motor drive
(SA/SAR 16.1 for AD90 motor)
Sub-assembly
155.0 Reduction gearing Sub-assembly
500.0 Cover for switch compartment Sub-assembly
501.0 Socket carrier (complete with sockets) Sub-assembly
502.0 Pin carrier without pins Sub-assembly
503.0 Socket for controls Sub-assembly
504.0 Socket for motor Sub-assembly
505.0 Pin for controls Sub-assembly
506.0 Pin for motor Sub-assembly
507.0 Plug cover Sub-assembly
511.0 Screw plug Sub-assembly
514.0 Output drive form A (without stem nut) Sub-assembly
514.1 Axial needle roller bearing Sub-assembly
516.1 Output drive shaft D
535.1 Snap ring
539.0 Screw plug
542.0 Handwheel with ball handle Sub-assembly
549.1 Output socket B3/B4/E
551.1 Parallel key
553.0 Mechanical position indicator Sub-assembly
554.0 Socket carrier with motor cable harness Sub-assembly
556.0 Potentiometer for position transmitter Sub-assembly
556.1 Potentiometer without slip clutch Sub-assembly
557.0 Heater Sub-assembly
558.0
Blinker transmitter including pins at wires
(without impulse disc and insulation plate)
Sub-assembly
559.0-1
Control unit without torque heads swit-
ching and switches
Sub-assembly
559.0-2
control unit with magnetic limit and torque
transmitter (MWG) for Non-intrusive versi-
on in combination with AUMATIC integral
controls
Sub-assembly
560.0-1 Switch stack for direction OPEN
560.0-2 Switch stack for direction CLOSE Sub-assembly
560.1 Switch for limit/torque switching
560.2 Switch case
566.0 Positioner transmitter RWG Sub-assembly
566.1 Potentiometer for RWG without slip clutch Sub-assembly
566.2 Electronic board RWG Sub-assembly
566.3 Wire harness for RWG Sub-assembly
567.1 Slip clutch for potentiometer/RWG Sub-assembly
568.1 Stem protection tube (without cap)
568.2 Cap for stem protection tube
568.3 V-seal
569.0 Change-over lever assy
569.1 Change-over lever
569.2 Notched pin
574.1 Radial seal output drive A for ISO flange
575.1 Stem nut type A
S1 Seal kit, small Set
S2 Seal kit, large Set
No. Designation Type No. Designation Type
