Version 15.01, July 2013
Rohde & Schwarz R&S ® FSH4/R&S ® FSH8/R&S ® FSH13/ R&S ® FSH20 Spectrum Analyzer 19
R&S ® FSH-K50/R&S ® FSH-K51 LTE FDD/TDD downlink pilot channel and EVM
measurement application 2
R&S ® FSH-K50E/R&S ® FSH-K51E LTE FDD/TDD downlink extended channel
and modulation measurement application 2
The specifications below apply to the R&S ® FSH4 and R&S ® FSH8. They are based on the data sheet specifications of the R&S ® FSH4
and R&S ® FSH8, have not been checked separately and are not verified during instrument calibration. Measurement uncertainties are
indicated as 95 % confidence intervals. The specified level measurement errors do not take into account systematic errors due to
reduced signal-to-noise ratio (S/N).
Measurements R&S ® FSH-K50/R&S ® FSH-K51 R&S ® FSH-K50E/R&S ® FSH-K51E
Spectrum overview ● ●
Result summary ● ●
RF channel power ● ●
Carrier frequency error ● ●
I/Q offset ● ●
Cell identity ● ●
Cyclic prefix ● ●
Reference signal power ● ●
PSYNC power ● ●
SSYNC power ● ●
PBCH power ● ●
PCFICH power ● ●
PDSCH power ● ●
Reference signal EVM ● ●
PSYNC EVM ● ●
SSYNC EVM ● ●
PBCH EVM ● ●
PCFICH EVM ● ●
PDSCH EVM ● ●
Isotropic antenna ● ●
Limits screen ● ●
Constellation diagram – ●
PSYNC – ●
SSYNC – ●
QPSK – ●
16QAM – ●
64QAM – ●
BTS scanner – ●
Cell identity – ●
PSYNC power – ●
SSYNC power – ●
Resource allocations – ●
All specifications are valid for SNR > 30 dB.
2 R&S ® FSH-K50/R&S ® FSH-K51/R&S ® FSH-K50E/R&S ® FSH-K51E options require instruments with serial number ≥ 105000.
Frequency range 15 MHz to 3.0 GHz
Supported channel bandwidths 1.4/3/5/10/15/20 MHz
Carrier frequency uncertainty
Lock range
±10 kHz
Measurement uncertainty SNR > 30 dB,
∆f
ref
= uncertainty of reference frequency
< 10 Hz + ∆f
ref
RF channel power
Measurement range
frequency > 15 MHz
preamplifier = off –60 dBm < P
RF channel
< 20 dBm
preamplifier = on –75 dBm < P
RF channel
< 20 dBm
Measurement uncertainty –75 dBm < P
RF channel
< 20 dBm,
ref. level adjusted to RF channel power
< 1 dB, typ. 0.5 dB
EVM
Measurement range
–50 dBm < P
RF channel
< 10 dBm, 860 MHz < frequency < 2.69 GHz,
E-UTRA test model 3.1, bandwidth 10 MHz, reference signal and PDSCH
Residual EVM < 2.5 %, typ. 2.0 %
