Data Sheet l MG3710A
Arbitrary Waveform Generator
Waveform Resolution
14, 15, 16 bits for each I/Q
Modulation Bandwidth
160 MHz ∗ /120 MHz
Reconstruction Filter
80 MHz
Baseband Level Adjustment (RMS Value Tuning)
Adjustable Input Level to Quadrature Modulator
Decrease level: Decreases distortion
Increase level: Improves noise floor
Variable Range: ±8 dB
Resolution: 0.01 dB
Marker Output
Waveform Resolution
14 bits: Waveform Pattern: 3 signals, or Internal Generated: 3 signals
15 bits: Waveform Pattern: 1 signal, or Internal Generated: 3 signals
16 bits: Internal Generated: 3 signals
Supports switching Positive/Negative logic pulse outputs
Internal Baseband Reference Clock
Range: 20 kHz to 200 MHz ∗ /160 MHz
Resolution: 0.001 Hz
External Baseband Reference Clock
with MG3710A-017
Range: 20 kHz to 50 MHz ∗ /40 MHz
Frequency Division, Multiplier Function: Internally Generate1, 2, 4, 8, 16, 1/2, 1/4, 1/8, 1/16 times input signals, and use as DAC Sampling Clock
Input Connector: BNC-J (Rear panel, BB REF CLK Input)
Input Level: ≥0.2 Vp-p, 50Ω (AC coupled) (nom.)
Selects external input and MIMO connection (BB Ref Sync)
Waveform Memory
1stRF
When MG3710A-048 is installed, both memory A and memory B must have the same capacity. A combination of different capacities is not available.
without MG3710A-045/046
64 Msamples
with MG3710A-045, without MG3710A-046
256 Msamples
without MG3710A-045, with MG3710A-046, or with MG3710A-045/046
1024 Msamples
2ndRF
When MG3710A-078 is installed, both memory A and memory B must have the same capacity. A combination of different capacities is not available.
without MG3710A-075/076
64 Msamples
with MG3710A-075, without MG3710A-076
256 Msamples
without MG3710A-075, with MG3710A-076, or with MG3710A-075/076
1024 Msamples
Number of loadable files
The following numbers of waveform patterns are available per waveform memory:
Max. Package Count: 4096
Max. Patterns per Package: 4096
The maximum number of patterns in total: 4096/waveform memory
The minimum number of samples per pattern: 128
Combination of Baseband Signal Function
1st VSG: with MG3710A-048
This function synthesizes the signals of two memories to generate a baseband waveform.
2nd VSG: with MG3710A-078
This function synthesizes the signals of two memories to generate a baseband waveform.
∗ : Supports firmware version 2.00.00 and later. Only when using MX370111A
WLAN IQproducer and MX370111A-002 802.11ac (160 MHz) option.
