Data Sheet l MG3710A
17
Phase Modulation (PM)
Internal modulation only; Specifications for modulated CW signal
PM Deviation
Range: 0 rad. to 160 rad., or [40 MHz ÷ Modulation Rate] (smaller value)
Resolution: 0.001 rad.
(Output Level: ≤+4 dBm, 100 kHz + 2 × (Modulation Rate + 2 × PM Deviation × Modulation Rate) ≤ f ≤ 2.7 GHz, after CAL)
Deviation Accuracy
<2% of setting + 0.02 rad. (nom.) (Modulation Rate: 1 kHz, ΦM Source = Sine, PM Deviation: ≤20 rad.)
Distortion
<0.2% (nom.) (Modulation Rate: 1 kHz, ΦM Source = Sine, PM Deviation: 20 rad.)
Modulation Frequency Response
Applied only to the internal modulation (Int) when MG3710A-050/080 is not installed.
Deviation: 2 rad., Bandwidth: ±1 dB
Int: 20 Hz ≤ Modulation Rate ≤ 20 kHz (nom.)
Ext DC coupling: DC ≤ Modulation Rate ≤ 20 kHz (nom.)
Ext AC coupling: 20 Hz ≤ Modulation Rate ≤ 20 kHz (nom.)
Pulse Modulation
On/Off Ratio
>70 dB (50 MHz ≤ f ≤ 3 GHz)
>60 dB (3 GHz < f ≤ 6 GHz)
Minimum Pulse width
1 µs (nom.)
Rise/Fall Time
≤50 ns (nom.) (10 to 90%)
Pulse Repetition Frequency
DC to 1 MHz (Duty: 50%)
External Pulse Modulation Input
AUX Connector (Rear panel), TTL
H: RF On, L: RF Off
Internal Modulation Signal
Waveform
Sine wave, Triangular wave, Square wave, Ramp wave (Positive or Negative)
Modulation Rate
Sine wave: 0.01 Hz to 40 MHz or (50 MHz – FM Deviation)
Triangular wave, Square wave, Ramp wave: 0.01 Hz to 4 MHz or (5 MHz – FM Deviation)
Frequency Resolution
0.1 Hz
Phase
–180 deg to 180 deg
Phase Resolution
0.1 deg
Additional Analog Modulation Input
When MG3710A-050/080 is installed and for 1st SG and 2nd SG respectively
Modulation Type
AM, FM, ΦM
Input Impedance
50Ω/600Ω/Hi-Z (100 kΩ/70 pF) (nom.)
Coupling
DC or AC is alternatively selectable.
The lower limit frequency for AC is 20 Hz (typ.).
Input Level
For set value, 2 Vp-p (nom.)
Simultaneous Modulation
AM + FM
AM + ΦM
Internal 1 + Internal 2
Internal + External
FM and ΦM cannot enabled simultaneously.
