Step 1.

Choose your bandwidth and channel count.

InfiniiVision 2000 X-Series scopes

2002A

2004A

2012A

2014A

2022A

2024A

Bandwidth* (–3 dB)

70 MHz

100 MHz

200 MHz

Calculated rise time (10-90%)

≤ 5 ns

≤ 3.5 ns

≤ 1.75 ns

Input
channels

DSOX

MSOX

2 + 8

4 + 8

2 + 8

4 + 8

2 + 8

4 + 8

* For example, if you chose 100 MHz, 2+8 channels, the model number will be MSOX2014A.

Step 2.

Tailor your scope with measurement applications to save time and money

Application

2000 X-Series

1 Megapoint memory upgrade

DSOX2MEMUP (-010)

Embedded serial triggering and analysis (I²C, SPI)

DSOX2EMBD (-LSS)

Computer serial triggering and analysis (RS232/422/485/UART)

DSOX2COMP (-232)

Automotive serial triggering and analysis (CAN, LIN)

DSOX2AUTO (-AMS)

WaveGen (built-in function generator)

DSOX2WAVEGEN (-001)

Integrated digital voltmeter

DSOXDVM (-DVM)

Educator’s kit

DSOXEDK (-EDK)

Mask testing

DSOX2MASK (-LMT)

Segmented memory

DSOX2SGM (-SGM)

InfiniView oscilloscope analysis software

N8900A

Agilent spectrum visualizer (ASV)

64997A

1. See pages 20-21 for more detailed information on upgradability, and installation process.

Step 3.

Choose your probes

Probes

2000 X-Series

N2862B 150 MHz 10:1 passive probe

Standard one per channel for 70 and 100 MHz models

N2863B 300 MHz, 10:1 passive probe

Standard one per channel for 200 MHz models

N6459-60001 8-channel logic probe and accessory kit

Standard on MSO models or with DSOX2MSO upgrade

N2889A 350 MHz 10:1/1:1 passive probe

Optional

10070D 20 MHz 1:1 passive probe with probe ID

Optional

10076A 250 MHz 100:1, 4 kV high-voltage passive probe with probe ID

Optional

N2791A 25 MHz, ±700 V high-voltage differential probe

Optional

N2792A 200 MHz 10:1 differential probe

Optional

1146A 100 kHz, 100 A, AC/DC current probe

Optional

2. See page 20 for probe compatibilty

table.

For more information on probes and accessories, see the Agilent literature 5968-8153EN

Step 4.

Add the final touches.

Recommended accessories

2000 X-Series

LAN/VGA connection module

DSOXLAN

GPIB connection module

DSOXGPIB

Rack mount kit

N6456A

Soft carrying case and front panel cover

N6457A

Hard copy manual

N6458A

Front panel cover (only)

N2747A
