15
Channel power
Amplitude accuracy, W-CDMA or IS95 (20 to 30 °C,
attenuation = 10 dB)
± 0.82 dB (± 0.23 dB 95th percentile)
Occupied bandwidth
Frequency accuracy ± [span/1000] (nominal)
Adjacent channel power
Accuracy, W-CDMA (ACLR)
(at specific mixer levels and ACLR ranges)
Adjacent Alternate
MS
BTS
± 0.14 dB
± 0.49 dB
± 0.21 dB
± 0.44 dB
Dynamic range (typical)
Without noise correction
With noise correction
–73 dB
–78 dB
–79 dB
–82 dB
Offset channel pairs measured 1 to 6
ACP measurement and transfer time (fast method) 14 ms (nominal) (σ = 0.2 dB)
Multiple number of carriers measured Up to 12
Power statistics CCDF
Histogram resolution 0.01 dB
Harmonic distortion
Maximum harmonic number 10th
Result Fundamental power (dBm), relative harmonics power (dBc),
total harmonic distortion in %
Intermod (TOI) Measure the third-order products and intercepts from two tones
Burst power
Methods Power above threshold, power within burst width
Results Single burst output power, average output power, maximum power, minimum
power within burst, burst width
Spurious emission
W-CDMA (1 to 3.6 GHz) table-driven spurious signals;
search across regions
Dynamic range
Absolute sensitivity
96.7 dB
–85.4 dBm
101.7 dB (typical)
Spectrum emission mask (SEM)
cdma2000® (750 kHz offset)
Relative dynamic range (30 kHz RBW)
Absolute sensitivity
Relative accuracy
78.9 dB
–100.7 dBm
± 0.12 dB
85.0 dB (typical)
3GPP W-CDMA (2.515 MHz offset)
Relative dynamic range (30 kHz RBW)
Absolute sensitivity
Relative accuracy
81.9 dB
–100.7 dBm
± 0.12 dB
88.2 dB (typical)
PowerSuite Measurement Specifications
