0300072-J0 RevA Page 31 of 46
Min. Current for Discharge Alarm -2 Amps x
Boost Automatic False x
Boost Activation Low Voltage 46.0 Vdc x
Boost Termination Voltage 56.4 Vdc x When reached ; back to Float
Boost Termination Current 2 Amps x When reached ; back to Float
Boost Termination Time 120 minutes x When reached ; back to Float
Battery Test (BT) End Voltage 46.0Vdc x
BT Discharge Ratio 0% x Editable with Battery licence
BT Interval 0 day x No automatic test, manual start only
BT Discharge Current 1000 Amps x
BT Min. Discharge Current 2 Amps x
BT Time Out 10 minutes x
Digital input 1 Name Digital input 1 x
Digital input 2 Name Digital input 2 x
Digital input 3 Name Digital input 3 x
Digital input 4 Name Digital input 4 x
Read Access Users 1, 2, 3, 4, 5 x
Write Access Users 0 x
Table 5 : Overview factory settings MCU
4.3.3 54 Vdc Bus Voltage
The float voltage at +25°C can be adjusted. In the edit mode, go to the DC System tab and click on
“Configuration”. Figure 28 below shows the Bus voltage screen through which setting changes can be made by
entering a new value and clicking on “Modify”. It is important to note that these values will be used as references
for alarms.
