0300072-J0 RevA Page 30 of 46
Table 4 summarises the features of each license (for more details refer to the Comp@s manual).
Description License
1. Basic 2. Battery 3. Asset 4. Modbus
Float voltage, TC, LVD    
Boost functions 
DC Bus alarms    
Battery continuity    
Battery temperature    
Battery max. charging current    
Battery Test 
Alarm settings: outputs , input    
PLC functions  
Serial Nr, Manufacturing date, ID  
Users (user name, PW)    
SNMP, XML    
Data records  
Modbus RTU over TCP protocol 
Table 4: Short-form license overview
4.3.2 Factory Preset Settings Overview
Table 5 lists all the default settings of the MCU.
Table Item Value
Licence
Comment
1 2 3
General URL address 192.168.45.2 x
User (as administrator ) admin x Case sensitive
Password compas x Case sensitive
Config.Table DC Bus Float 54.0 Vdc x At +25°C ; 2.25 Vdc/cell
DC Bus Voltage Extra Low 45.0 Vdc x 1.88Vdc/ cell
DC Bus Voltage Low 48.0 Vdc x 2.00Vdc/cell
DC Bus Voltage High 56.5 Vdc x 2.35Vdc/cell
DC Bus Voltage Extra High 58.0 Vdc x 2.42Vdc/cell
LVD Disconnect Voltage 43.2 Vdc x 1.80Vdc/cell
LVD Disconnect Delay 0 x
Temp. Comp. slope -72 mVdc x
Only applied when system is in float -3
mVdc/K/cell
Minimum nr. of Present Rectifiers 0 x
Battery Charge Current Limit / x No battery charging current limitation
Battery String Capacity 62 Ah x
Bat. Temp. Low 0°C x
Bat. Temp. High +40°C x
