CFR 3000 and 3000RM
iv
Table of Contents
The emergency shutdown procedure is on the inside rear cover
1. Introduction
.........................................
1
1.1 The CFR Advantage .................................. 2
1.2 Unpacking and Inspection Checklist ......... 3
1.3 The Alpha CFR 3000 and 3000RM ............ 5
2. Installation
..........................................
10
2.1 Pre–Installation Checklist ....................... 11
2.2 Installing the Unit ................................... 13
2.3 Connecting the Unit ................................ 15
2.4 Connecting the External Battery Packs .. 18
2.5 Connecting the External Alarm Port ....... 20
2.6 Connecting the LAN Port ........................ 21
2.7 Connecting the RS–232 Port .................. 22
2.8 Transformer Output Load Sharing ........... 23
3. Operation
............................................
26
3.1 Turning On the Unit ................................ 27
3.2 Turning Off the Unit ................................ 29
3.3 Testing the Unit ...................................... 30
3.4 Troubleshooting with the SID .................. 31
3.5 Controlling the Unit with the Standard
Interface Device ..................................... 32
4. Communication
.............................
35
4.1 RS–232 Set-Up ...................................... 36
4.2 Using the Opening Menu ........................ 38
4.3 Menu Tree .............................................. 41
4.4 System, Input, Output & Battery Param-
eters ...................................................... 42
4.5 User Parameters .................................... 45
4.6 Maintenance Parameters ....................... 49
4.7 Installing and Using the External Modem 50
5. Maintenance
....................................
58
5.1 Testing the Battery Run Time ................. 59
5.2 Troubleshooting ...................................... 60
5.3 Returning the CFR to Alpha for Repairs .. 62
5.4 Replacing the Internal Batteries .............. 62
5.5 Configuring the Input/Output Voltage ...... 67
5.6 Battery Run Times ................................. 70
5.7 Specifications ......................................... 72
Index ............................................ 73
Warranty ...................................... 78
