Recording
98
 At Copy you can take on this setting for other days or
the whole week.
6. Finalize your settings in the record screen with Apply
and then OK.
Encoding
TAB Record
The following setting possibilities are available in this
sub-menu:
Camera Camera to be set
Input Resolu-
tions displays the incoming, and thus the
maximum, resolution of the camera
Encoding Pa-
rameters Stream 1: Properties for continuous
recording
Stream 2: Properties for event re-
cording (Alarm / motion)
Stream 3: Properties for network
transmission
Stream Type Video
Video & Audio
Resolution 1920x1080, 1280x720,
4CIF(704x576), CIF(352x288),
Bitrate Type In general, the higher the bit rate, the
more storage space is required.
Variable:
Static image – low bit rate; dynamic
image – high bit rate
Constant:
Bit rate remains constant (at maxi-
mum bit rate)
Video Quality There are various quality levels:
+: Low quality
++++++: High quality
Frame Rate Number of images saved per second.
The maximum number is dependent
on the set resolution.
Max. Bitrate-
Mode Select between free entry of bit rate /
list of standardized bit rates
Max. Bitrate
(Kbps) Defines the maximum bit rate for the
“Constant” bit rate type
1. Select the camera.
2. Select the stream where the specifications should be
defined:

Stream 1 (Continuous)
 Stream 2 (Event)
 Stream 3 (Network)
3. Define the recording parameters for the correspond-
ing stream (see table).
4. Under More, select the period for the pre-alarm,
post-alarm etc.
5. Click on Copy to take on these settings for other
cameras.
For detailed settings click on More.
Confirm the settings by clicking on Apply and leave the
menu with OK.
Pre-record Recording period before an alarm
(in seconds)
Post-record Recording period after an alarm
(in seconds)
Expired Time (day) Period (in days) after which the
recording is deleted automatically
at 00:00. The event remains in the
log file.
0: Recordings are not deleted
automatically
Redundand Re-
cord/... Choose wheter the data shall be
overwritten when HDD is full
Record Audio Audio record yes/no
