System operation
77
Connections on the rear of the device
Note
Pay attention to the overview on page 66.
No. Name
Function
8 VIDEO IN: BNC inputs
9 MAIN: BNC video output
 When using a HDMI/VGA monitor:
Scalable live display.
 When using no HDMI/VGA monitor:
The main video signal is displayed.
10 AUDIO OUT:
 Cinch audio output (synchronised with main
video signal output)
11 LINE IN:
 Cinch audio input (is not recorded, only for
network transmission)
12 RS-232:
 Serial port – no functionality
13 eSATA connection
14 Mains power connection:
 100–240 V AC, 50–60 Hz
15 Power switch
16 AUDIO IN:
Cinch inputs
Assigned to camera inputs 1 - 4
17 VGA:
 VGA monitor connection (9-pin), video output
signal
18 HDMI:
 HDMI monitor connection
19 LAN:
 Ethernet LAN connection 1+2
20 ALARM IN:
 RS-485 connection for PTZ cameras
 Max. 4 alarm inputs
ALARM OUT:
 Max. 2 relay outputs
Operating elements on the remote control
Note
Pay attention to the remote control diagram on
page 67.
No. Name
Function
21 DEV:
Assigns the remote control with the device ID
22 Alphanumeric keys:
 Selects the camera (channel) in the live view
 Entry of letters and digits in system fields
23 A:
Changes the entry format (upper / lower case,
symbols, digits)
24 PLAY:
Starts playback
25 VOIP:
 Not used
26 PREV:
Changes the screen display in the live view
27 Navigation keys:
During playback:
 ,  Sets the speed
 ,  Previous / next day
In the live view:
 Selects the camera (channel selection)
In menus:
 Navigation
28 ESC:
 Not used
