Configuration
110
IP Alarm Module
You can add ABUS IP alarm modules (CASA10010)
here. After successfully connecting via the network, two
alarm inputs and two alarm outputs are added to each of
the “Alarm Input” and “Alarm Output” tabs. The short
name of the inputs is
U1<-1 / U1<-2, whilst the short name of the outputs is
U1->1 / U1->2.
Click on “Add” to configure an ABUS IP alarm module.
Parameter
Setting
IP Alarm Modu-
le
A unique name for the IP alarm mod-
ule can be entered here.
IP Address
Enter the IP address of the IP alarm
module here.
Manage Port
Enter the port (default: 8000) of the IP
alarm module here.
Admin Name
Enter the user name of the IP alarm
module here (user must have admin-
istrator rights).
Password
Enter the password of the user speci-
fied above here.
After a successful connection two virtual alarm in- and
outputs are added. These can only be switch by network.
Note
Please refer to the homepage (www.abus-sc.com)
to find further installation instructions in the down-
load section of the ABUS IP Alarm Module
(CASA10010).
RS-232
Currently no functioning.
Live view
See page 84.
Warning
Note
Enter the trigger under “Exception Type”, for ex-
ample:
HDD
Full
Disconnected
After doing this, specify the device behaviour as
detailed on page 38.
Confirm the settings by clicking Apply and leave the
menu with Back.
User
Warning
Note down the admin password.
The following password is preset
