System operation
78
No. Name
Function
29 Not used
30 Not used
31 Zoom +:
Zooms in on the image section in PTZ mode
32 F1:
In lists:
 Selects all available options
33 Zoom -:
Zooms out of the image section in PTZ mode
34 F2:
Switches between tabs
35 IRIS-: In PTZ mode:
 Closes the iris
36 Focus-: In PTZ mode:
 Brings the image section into focus
37 IRIS+: In PTZ mode:
 Opens the iris
38 Focus+: In PTZ mode:
 Brings the image section into focus
39 ◄II: Pause / reverse playback
40  : Stops playback
41 PTZ:
Switches on PTZ control
42 Enter II:
 Confirms the selection
 Ticks / unticks the boxes
During playback:
 PLAY/PAUSE
Single play mode:
 Advances by a single frame
43 MENU:
 Calls up the main menu
 Switches the key tones on and off (press and
hold down for 5 seconds)
44 REC:
Opens / starts manual recording
No. Name
Function
45 INFO:
 Switches to another monitor in the live view
46 EDIT:
General use:
 Activates the text entry; backspace in text
fields
47 POWER:
Switches on/off (hold down for 5 seconds)
Mouse operation
Note
Further descriptions in these operating instruc-
tions are made with the mouse.
The device is suitable for use with a USB mouse.
Connect the mouse to the USB port.
Button Function
Left
Single-click:
 Selection in menu, activation of an entry
field or tab
Double-click:
 Switches between the screen display of
single and multiple images in the live view
and during playback
Click and drag:
 In PTZ mode: Camera control
 Set-up of alarm areas or zones
Right Single-click:
 Calls up the pop-up menu
Scroll
wheel In the live view:
 Shows previous / next camera
In menus:
 Scrolls through the menus
