Playback
87
Playback
General information
Playback can be made in three different ways:
 Through the video search in the main menu
 From the live view
 Through the log file in the maintenance menu
Note
The buttons “previous file/day/event” are used dif-
ferently depending on the playback mode:
Normal playback:
By pressing the button the playback jumps to the
previous/next day.
Video Search:
By pressing the button the playback jumps to the
previous/next event day.
Video Export:
By pressing the button the playback jumps to the
previous/next file.
Note
It is possible to start a simultaneous playback with
up to 4 cameras.
Playback screen
Playback is controlled on the control panel:
No. Area

Running playback with date and time
 Used to select the camera for feedback
 Calendar with recording type
 Control panel with time bar (see right)
Using the control panel
The control panel (4) is used for controlling the running
playback. The symbols have the following meaning:
No. Meaning / function
1
Zoom in / Zoom out the time line (24/12/1 hours)
2 Audio playback switch on/ off
3 Define start point / end point of a video for secur-
ing data
4 Add marking
5 Add user-defined marking
6 Administer marking
7 Backwards playback
8 Stop
9
Playback start / pause
10 Jump backward 30 seconds
11 Jump forward 30 seconds
12 Slow forward (slow motion) (1/16x - 1x)
13 Fast forward (1x - 16x)
14 Previous recording, previous day
15 Next
file/day/event
16 Time bar:
 Click on the time bar with the mouse to con-
tinue playback from another point
 To start playback from a specific time, click on
the slider and drag it to the required time
17 Recording type
Blue = Continuous recording
Red = Event recording
18 Hides the control panel
19 Exits playback
(1)
(2) (3) (4) (5) (6)
(7) (8) (9) (10)(11) (12) (13) (14) (15)
(16)
(17) (18) (19)
 


