Steps to Start Using TSA Upgrade Tool for logging DTU Quality
The feature of the TSA Upgrade Tool (Figure 11) allows technicians to either poll the console for the most current signal
quality value or log on a continuous basis
.
192.168.168.168
DTU Logging Tab
Check to log the DTU
Quality to your computer
Polls the console once
Polls the console
continuously
How often to poll
the console when in
continuous mode
Figure 11; TSA Upgrade Tool
