CLA-VAL
Copyright Cla-Val 2011 Printed in USA Specifications subject to change without notice.
P.O. Box 1325
• Newport Beach, CA 92659-0325 • Phone: 949-722-4800 • Fax: 949-548-5441 • E-mail: [email protected] • Website cla-val.com
©
Input Voltage:
120/240 Vac +/- 10%, 50/60 Hz
Operating Current:
2 Amperes at 120 Vac
Process Variable:
Field Selectable between 4-20mA
transmitter (supplied by others)
or internal potentiometer
Loop Power Supply:
0-24 VDC
Retransmission:
Isolated non-powered 4-20mA
Input Signal Monitor:
If process variable is lost actuator
holds in present position, opens or
closes, field selectable
Setpoint:
Field selectable between local
and remote 4-20 mA, 0-5 Volt, 0-10 Volt
Manual Adjustment:
Non-rotating handwheel
Limit Switches:
Electronic-Full range adjustable
Terminations:
Terminal blocks accepting up to
#16 Awg solid or stranded wire
Operating Temperature: 0°F to 150 °F (-18 C to 65 C)
Environmental Rating:
Enclosure rated NEMA type 4
indoor/outdoor, corrosion resistant
aluminum
Adjustment Ranges
2 to 30
psi
15 to 75 psi
20 to 105 psi
30 to 300 psi
Temperature Range
Water: to 180°F
Materials
Standard Pilot System Materials
Pilot Control: Bronze ASTM B62
Trim: Stainless Steel Type 303
Rubber: Buna-N
®
Synthetic Rubber
Optional Pilot System Materials
Pilot Systems are available with optional Aluminum,
Stainless Steel or Monel materials.
Note: Available with remote sensing control. Consult Factory
Pilot System Specifications
Electronic Actuator - CRD-30 Pilot Control
Many factors should be considered in sizing pressure reducing valves including inlet pressure, outlet
pressure and flow rates. For sizing questions or cavitation analysis, consult Cla-Val with system details.
We recommend providing adequate space
around valve for maintenance work
E-393-01/3693-01 (R-7/2011)
When Ordering, Please Specify
1. Catalog No. 393-01 or 3693-01
2. Valve Size
3. Pattern - Globe or Angle
4. Pressure Class
5. Threaded or Flanged
6. Trim Material
7. Adjustment Range
8. Desired Options
9. When Vertically Installed
10. Energized or de-energized
to open Main Valve
11. Solenoid Voltage
3693-01
Valve
Selection
100-20 Pattern:
Globe (G), Angle (A),
End Connections:
Flanged (F) Indicate Available Sizes
Inches
3
4
6
8
10
12
14
16
18
20
24
30
36
42
48
mm
80
100
150
200
250
300
350
400
450
500
600
750
900
1000
1200
Basic Valve
100-20
Pattern
G
G, A
G, A
G, A
G
G
G
G
G
G
G
G
G
G
G
End Detail
F
F
F
F
F
F
F
F
F
F
F
F
F
F
F
Suggested
Flow
(gpm)
Maximum
260
580
1025
2300
4100
6400
9230
9230
16500
16500
16500
28000
33500
33500
33500
Minimum
1
2
4
10
15
35
50
50
95
95
95
275
450
450
450
Suggested
Flow
(Liters/Sec)
Maximum
16
37
65
145
258
403
581
581
1040
1040
1040
1764
2115
2115
2115
Minimum
.06
.13
.25
.63
.95
2.2
3.2
3.2
6.0
6.0
6.0
17.4
28.4
41.0
41.0
100-20 Series is the reduced internal port size version of the 100-01 Series.
For Lower Flows Consult Factory
393-01
Valve
Selection
100-01 Pattern:
Globe (G), Angle (A),
End Connections:
Threaded (T), Grooved (GR), Flanged (F) Indicate Available Sizes
Inches
1
1
1
⁄
4
1
1
⁄
2
2
2
1
⁄
2
3
4
6
8
10
12
14
16
18
20
24
30
36
mm
25
32
40
50
65
80
100
150
200
250
300
350
400
450
500
600
750
900
Basic Valve
100-01
Pattern
G, A G, A G, A G, A G, A G, A G, A G, A G, A G, A G, A G, A G, A
G
G
G, A
G
G
End Detail
T
T
T, F,
Gr*
T, F,
Gr
T, F,
Gr*
T, F,
Gr
F,
Gr
F,
Gr*
F,
Gr*
F
F
F
F
F
F
F
F
F
Suggested
Flow
(gpm)
Maximum
55
93
125
210
300
460
800
1800 3100 4900 7000 8400 11000 14000 17000 25000 42000 50000
Maximum
Intermittent
68
120
160
260
370
580
990
2250 3900 6150 8720 10540 13700 17500 21700 31300 48000 62500
Minimum
1
1
1
1
2
2
4
10
15
35
50
70
95
120
150
275
450
650
Suggested
Flow
(Liters/Sec)
Maximum
3.5
6
8
13
19
29
50
113
195
309
442
530
694
883
1073 1577 2650 3150
Maximum
Intermittent
4.3
7.6
10
16
23
37
62
142
246
387
549
664
863
1104 1369 1972 3028 3940
Minimum
.03
.03
.03
.06
.09
0.13
0.25
0.63
0.95
2.2
3.2
4.4
6.0
7.6
9.5
17.4
28.4
41.0
100-01 Series is the full internal port Hytrol.
For Lower Flows Consult Factory
*
Globe Grooved Only
